Published 2026-10-07 · DIYCarPlay Engineering Team
CarPlay Retrofit Kit Price: What a Factory Quote Should Itemise
A CarPlay retrofit kit price is not a single number — it is a function of the head unit platform, the order quantity, the branding level and the firmware scope. A usable factory quotation itemises all four separately, so two quotes that both look like a single unit price are rarely comparable. This matters most for importers and installers buying for resale, where the gap between the quoted figure and the real landed cost decides whether the programme works.
A retrofit module is a small Linux-embedded box that plugs into the vehicle's existing wiring and puts CarPlay on the screen already fitted to the dashboard. It is not a replacement display, and the price of a replacement display is not a useful benchmark. The original screen, the original head unit, the factory buttons and the original reversing camera all stay in the car. Apple documents what the phone side expects on its CarPlay support page, and the CarPlay entry on Wikipedia covers how the interface has moved between generations. Neither describes the module itself, which is where most of the cost sits.
Why one product carries many prices
The cheapest meaningful unit in this category and the most expensive one are frequently the same physical item with different paperwork. Four variables move the number, and they move it independently.
Platform. Every head unit generation needs its own firmware. A BMW CIC module and a Mercedes NTG4.5 module are not the same product with a different label; the LVDS timing, the wake-up handshake and the reverse-trigger logic all differ. Each platform is a separate development and a separate stock line.
Quantity. The break points are published: stock modules start at 10 pieces with mixed models allowed in one order, private label starts at 500 pieces per model, and full OEM firmware customisation starts at 1000 pieces per model. Small mixed orders carry the highest per-unit cost because setup is spread across few units.
Branding level. A plain module in a neutral box is a different cost structure from printed retail packaging with a distributor's own logo, manual and warranty card. Tooling and print setup are one-off costs, so they matter far more at 500 pieces than at 5000.
Firmware scope. A module shipping current firmware for its generation is a known article. Adding a platform, a language pack or a custom splash screen turns it into a development project with a different lead time entirely.
The platform list that determines the SKU
Before any price is meaningful, the platform has to be fixed. The fitment finder covers the full range; the structure a quote should be broken down against is set out in the table. Head unit generation, not model year alone, is what selects the module.
| Brand group | Head unit platforms | Year range |
|---|---|---|
| BMW (incl. MINI) | CIC / NBT / EVO | 2008–2025 |
| Mercedes-Benz | COMAND NTG4.0 / NTG4.5–NTG5.0 / HU6 | 2007–2025 |
| Audi | MMI 2G / MMI 3G / MIB2–MIB3 | 2009–2025 |
| Porsche | CDR 3.0 / PCM 3.1 / PCM 4.0–5.0 | 2010–2024 |
| Land Rover / Jaguar | JR-1 (Bose audio) | 2012–2015 |
| Volvo | Sensus VO-1 / VO-2 / VO-3 | 2010–2022 |
| Lexus | Infotainment gen 1 / gen 2 | 2013–2020 |
| Volkswagen | MIB | 2013–2018 |
| Toyota / Nissan / Honda | TO-1 / TO-2 / NI-1 / NI-2 / HO-1 | 2009–2022 |
| Luxury (Rolls-Royce, Bentley, Lamborghini, Aston Martin, Maserati, Alfa Romeo, Ferrari, McLaren) | Bespoke platforms per marque | 2006–2020 |
Nineteen brand groups and 300+ models and series sit behind that table. Buyers who try to order "a BMW module" without naming the generation end up paying for the wrong article; the identification guide exists to settle that before a purchase order is issued.
What a usable quotation should itemise
A quotation that gives one figure and nothing else cannot be compared against another quotation, because the two may not contain the same scope. Six lines should appear separately.
| Line | What must be stated | Why it changes the number |
|---|---|---|
| Unit price and tier | Price at each quantity band, and the band it applies to | Setup cost is amortised differently at 10, 100 and 1000 units |
| Platform | Head unit generation and firmware version per unit | Each platform is separate development and separate stock |
| Scope of work | Harness, camera input, button retention, language pack | Decides whether a platform is standard or a development |
| Branding | Neutral box vs printed retail packaging, logo, manual, warranty card | Tooling and print setup are one-off, so per-unit impact falls with volume |
| Lead time | Separate figures for samples and for production | Samples ship in 7–15 days by DHL or FedEx; 500+ pieces run 15–20 days |
| Terms | Payment schedule, Incoterm, warranty and returns handling | Determines the cash cost of the first order, not just the unit price |
The Incoterm line is frequently the one that gets skipped in an email thread and later becomes a dispute. FOB, CIF and DAP place the cost of freight and insurance on different sides, and the incoterm guide for car electronics importers sets out where each one bites.
Where the real cost hides: returns, not unit price
The line item that decides whether an import programme is viable is rarely the unit price. It is the return rate, because a returned unit costs far more than its margin: the module is written off, the customer relationship is spent, and the freight in both directions is paid for nothing. Return rates are driven by hardware choices that are visible in the specification.
Two choices do most of that work. First, an automotive-grade chipset from Taiwan's Sunplus rather than a general-purpose part, which is the same reason premium European head units stay responsive for years — the infotainment computers in those cars are themselves Linux machines. Second, dual-band WiFi using both 2.4GHz and 5GHz. The 2.4GHz band is congested in multi-storey car parks and underground structures; the 5GHz band is where the available headroom is. A single-band module that drops the link in a concrete basement generates a support call that costs more than the hardware saved.
This is also why Linux-embedded modules behave differently from an aftermarket Android head unit over a service life. An Android head unit requires replacing the factory screen, and it accumulates cached data as it runs, so a unit that feels quick on day one is not the same unit in year three. A Linux-embedded module that keeps the original screen accumulates nothing in the same way, because the operating system is not a general-purpose one being asked to run an interface on hardware it was never sized for.
The warranty and returns article covers the process side, and a supplier that has already written the process down is a supplier whose return rate has been measured rather than assumed.
What actually moves a price up or down
Four levers account for most of the spread between a high quote and a low one for the same nominal product. Checking them in order is faster than negotiating.
- Order shape. One platform at 500 units is a different production job from four platforms at 125 units each. Consolidation usually lowers the unit price even when the total spend is identical. The first-container SKU guide covers how to build that shape.
- Branding commitment. Staying at stock level avoids tooling entirely. It is the cheapest way to test whether a market exists before committing to 500 pieces of anything.
- Specification shorthand. A quote that says "CarPlay module" without naming the chipset generation, the band support or the platform is not comparable to one that does. Ask for the platform list as a line item.
- Payment terms. Standard terms are 30% deposit with the balance settled before shipment by T/T. PayPal is accepted for samples. The schedule is not a negotiating lever at the first enquiry, but it should be fixed in writing before the second order.
One further variable sits outside the factory entirely: duty and freight. Those depend on the destination and the Incoterm rather than on the product, and a per-unit price that looks competitive can still produce an unattractive landed cost once they are added.
Questions worth asking before a purchase order goes out
Six questions resolve most of the ambiguity, and all six can be answered in writing before money moves.
- Which head unit platforms does this price cover, at which firmware version?
- What are the price bands, and which band does this quantity fall into?
- Is the sample cost deducted from the first volume order?
- What is the production lead time once payment clears, separate from the sample lead time?
- What is the agreed return rate assumption, and what is the claims process?
- Which Incoterm applies, and who arranges the freight?
A factory that answers all six plainly has a process worth scaling with. One that answers two of them has not yet decided how it would handle a distributor order, and the price will change once it does.
Common pricing questions
Is a cheaper unit price always a better deal?
No. A lower price on a module that has not been tested against the target head unit, or that ships with a single-band radio, tends to reappear as a return and a support call. The comparison that matters is cost per retained unit, not cost per unit shipped.
What is the smallest order worth placing?
Ten pieces, with mixed models allowed in one order. That is the right size for verifying a platform before committing to a larger run, and it costs nothing in tooling.
How long does a first order take end to end?
Samples ship in 7–15 days by DHL or FedEx. Production of 500 pieces or more runs 15–20 days. Both figures are measured from cleared payment, so the payment schedule is part of the lead time rather than a separate formality.
Does private labelling change the price per unit much?
At 500 pieces per model it changes the unit price less than the setup cost does. The tooling and print setup are one-off, so the per-unit impact falls as the run grows. Above 1000 pieces per model, full OEM firmware customisation becomes the relevant tier.
How quickly should a quotation be expected?
A quotation is normally returned within 12 hours on business days, with a recommended configuration, a MOQ and a lead time for the platforms named in the enquiry. Naming the head unit platform in the first message is what makes that turnaround possible.
Requesting a quotation
Send the target vehicle list, the quantities per platform and the destination market through the inquiry form. A quotation comes back within 12 hours with volume tiers, a MOQ and lead times for the platforms named, and the wholesale programme options set out against the three commitment levels. Samples can be ordered at the same time and the sample cost is deducted from the first volume order.
